S9S12XS256J0VAL Microcontroller MCU 16-Bit MCU 40MHz HCS12X Microcontroller IC

S9S12XS256J0VAL Microcontroller MCU 16-Bit MCU 40MHz HCS12X Microcontroller IC​

Product Description Of S9S12XS256J0VAL

S9S12XS256J0VAL is available in 112-pin LQFP package options and maintains a high level of pin compatibility with the S12XE family. In addition to the I/O ports available in each module, up to 18 further I/O ports are available with interrupt capability allowing Wake-Up from stop or wait modes.
S9S12XS256J0VAL The peripheral set includes MSCAN, SPI, two SCIs, an 8-channel 24-bit periodic interrupt timer, 8-channel 16-bit Timer, 8-channel PWM and up to 16- channel 12-bit ATD converter.

Specification Of S9S12XS256J0VAL

Features Of S9S12XS256J0VAL

16-bit CPU12X
16-channel, 12-bit Analog-to-Digital converter
MSCAN (1 M bit per second, CAN 2.0 A, B software compatible module)
Up to 8 channel x 8-bit or 4 channel x 16-bit Pulse Width Modulator
Serial Peripheral Interface Module (SPI)
Two Serial Communication Interfaces (SCI)
Package: 112-pin low-profile quad flat-pack (LQFP)
Operating Conditions
— Wide single Supply Voltage range 3.135 V to 5.5 V at full performance
– Separate supply for internal voltage regulator and I/O allow optimized EMC filtering
— 40MHz maximum CPU bus frequency
— Ambient temperature range –40°C to 125°C

Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
