R5F10AGFCKFB Microcontroller MCU 16-Bit Single Chip Microcontrollers LQFP48 RL78 MCU

R5F10AGFCKFB Microcontroller MCU 16-Bit Single Chip Microcontrollers LQFP48 RL78 MCU
R5F10AGFCKFB Microcontroller MCU 16-Bit Single Chip Microcontrollers LQFP48 RL78 MCU
R5F10AGFCKFB Microcontroller MCU 16-Bit Single Chip Microcontrollers LQFP48 RL78 MCU R5F10AGFCKFB Microcontroller MCU 16-Bit Single Chip Microcontrollers LQFP48 RL78 MCU

Large Image :  R5F10AGFCKFB Microcontroller MCU 16-Bit Single Chip Microcontrollers LQFP48 RL78 MCU

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: R5F10AGFCKFB
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: LQFP-48
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

R5F10AGFCKFB Microcontroller MCU 16-Bit Single Chip Microcontrollers LQFP48 RL78 MCU

Description
Part Number: R5F10AGFCKFB Core Processor: RL78
Core Size: 16-Bit Speed: 24MHz
Number Of I/O: 38 Program Memory Size: 96KB (96K X 8)

R5F10AGFCKFB Microcontroller MCU 16-Bit Single Chip Microcontrollers LQFP48 RL78 MCU



Product Description Of R5F10AGFCKFB

R5F10AGFCKFB RL78/F13 microcontrollers are successors to the 78K0R and R8C, are available in a 48-pin, 96KB flash memory lineup and realize the industry's lowest level of consumption current. R5F10AGFCKFB have a built-in CAN module and LIN module for automotive interfaces, and in addition to the functional safety features, a RAM ECC function, PLL lock function, port output state monitoring, stack overflow detection, dedicated WDT oscillator and more have also been added.


Specification Of R5F10AGFCKFB

Series
RL78/F13
Core Processor
RL78
Core Size
16-Bit
Speed
24MHz
Connectivity
CSI, I2C, LINbus, SPI, UART/USART
Peripherals
LVD, POR, PWM, WDT
Number of I/O
38
Program Memory Size
96KB (96K x 8)
Program Memory Type
FLASH
EEPROM Size
4K x 8
RAM Size
6K x 8
Voltage - Supply (Vcc/Vdd)
2.7V ~ 5.5V
Data Converters
A/D 17x10b SAR
Oscillator Type
Internal
Operating Temperature
-40°C ~ 125°C (TA)
Mounting Type
Surface Mount
Supplier Device Package
48-LFQFP (7x7)
Package / Case
48-LQFP


Features Of R5F10AGFCKFB

CPU: RL78 core, Max. 24MHz
Voltage: 2.7V to 5.5V
Package: 48-pin LFQFP
Memory: SRAM Max. 6KB, Program Flash Max. 96KB
PWM: PWM Output x 16, 3-phase PWM Output Function
Analog function: A/D 17x10b SAR
Others: PLL, RTC, Power-On Reset, Low Voltage Detection


Applications Of R5F10AGFCKFB
Automotive Sensor with CAN/LIN Interface
In-Cabin Air Quality Sensor
Solid State Automotive Power Distribution Module
Bi-directional DC/DC Converter for 12V/48V EV/HEV Systems
Automotive Camera Solution with AHL Control Channel
12V Motor Controller
Sunroof Controller
Car Audio
Body
Chassis & Safety
HEV/EV
Motor Control
