STM32L071RBH6 Microcontroller MCU 32Bit Single Core Microcontrollers 32MHz Embedded MCU

STM32L071RBH6 Microcontroller MCU 32Bit Single Core Microcontrollers 32MHz Embedded MCU​

Product Description Of STM32L071RBH6

STM32L071RBH6 is high-performance Arm Cortex-M0+ 32-bit RISC core Microcontrollers, operating at a 32 MHz frequency, a memory protection unit (MPU), high-speed embedded memories (up to 192 Kbytes of Flash program memory, 6 Kbytes of data EEPROM and 20 Kbytes of RAM) plus an extensive range of enhanced I/Os and peripherals.

Specification Of STM32L071RBH6

Features Of STM32L071RBH6

Ultra-low-power platform
- 1.65 V to 3.6 V power supply
- -40 to 125 °C temperature range
- 0.29 µA Standby mode (3 wakeup pins)
- 0.43 µA Stop mode (16 wakeup lines)
- 0.86 µA Stop mode + RTC + 20-Kbyte RAM retention
- Down to 93 µA/MHz in Run mode
- 5 µs wakeup time (from Flash memory)
- 41 µA 12-bit ADC conversion at 10 ksps
Core: Arm® 32-bit Cortex®-M0+ with MPU
- From 32 kHz up to 32 MHz max.
- 0.95 DMIPS/MHz
Memory
- Up to 192-Kbyte Flash memory with ECC(2 banks with read-while-write capability)
- 20 -Kbyte RAM
- 6 Kbytes of data EEPROM with ECC
- 20-byte backup register
- Sector protection against R/W operation
Up to 84 fast I/Os (78 I/Os 5V tolerant)
7-channel DMA controller, supporting ADC, SPI, I2C, USART, Timers
Up to 10x peripheral communication interfaces
- 4x USART (2 with ISO 7816, IrDA), 1x UART (low power)
- Up to 6x SPI 16 Mbits/s
- 3x I2C (2 with SMBus/PMBus)
