S9S12G96F0CLFR Microcontroller MCU 16-Bit 25MHz S12G General Purpose Automotive Microcontrollers
Product Description Of S9S12G96F0CLFR
S9S12G96F0CLFR is an optimized, 16-bit microcontroller product line focused on low cost, high performance and low pin count. The S12G is suited for generic automotive and industrial applications requiring CAN or LIN/SAE J2602 communication.
Product Attributes Of S9S12G96F0CLFR
|
Core Processor
|
|
|
Core Size
|
|
|
Speed
|
|
|
Connectivity
|
CANbus, IrDA, LINbus, SCI, SPI
|
|
Peripherals
|
|
|
Number of I/O
|
|
|
Program Memory Size
|
96KB (96K x 8)
|
|
Program Memory Type
|
|
|
EEPROM Size
|
|
|
RAM Size
|
|
|
Voltage - Supply (Vcc/Vdd)
|
|
|
Data Converters
|
|
|
Oscillator Type
|
|
|
Operating Temperature
|
|
Features Of S9S12G96F0CLFR
S12 CPU core, 25 MHz bus
Up to 240 KB on-chip flash with ECC
Up to 4 KB EEPROM with ECC
Up to 11 KB on-chip SRAM
Up to one multi-scalable controller area network (MSCAN) module
Supporting CAN protocol 2.0 A/B
Up to three serial communication interface (SCI) modules
Supporting LIN communications
Up to three serial peripheral interface (SPI) modules
Precision fixed voltage reference for analog-to-digital conversion (ADC)
1 MHz internal oscillator
On-chip voltage regulator for input supply and internal voltages
Applications Of S9S12G96F0CLFR
Automotive
Electric Pumps
Gateway
Heating Ventilation and Air Conditioning (HVAC)
Hybrid Electric Vehicle (HEV) Applications
Consumer
Air Conditioning (AC)
Major Home Appliances
Robotic Appliance
Small and Medium Appliances
Industrial
3-Phase AC Induction Motor
Automotive Gas Meter
Brushless DC Motor (BLDC) Control
Continuous Glucose Monitoring (CGM)
Heat Meter
Motion Control and Robotics
Patient Monitor
Permanent Magnet Synchronous Motor (PMSM)
POS Terminal
Power Grid Converter
Smart Power Socket
Smart Watch and Wristband
Vital Signs Monitors
Water Meter
