STM32L485JCY6TR Microcontroller MCU High-Performance 32-Bit Microcontroller Based On ARM Cortex-M4 Core
Product Description Of STM32L485JCY6TR
STM32L485JCY6TR is a high-performance 32-bit microcontroller based on the ARM® Cortex®-M4 core with low power consumption and rich peripheral interfaces for a wide range of embedded applications.
Specifications Of STM32L485JCY6TR
Core: ARM® Cortex®-M4 (with FPU floating point unit)
Operating frequency: 80MHz
Operating Voltage: 1.71V ~ 3.6V
Operating Temperature: -40°C ~ +85°C
Flash: 1MB (1024KB)
RAM: 128KB
EEPROM: None (Some STM32L4 series contain EEPROM, but it is not mentioned in this model)
ADC: 16 channels 12-bit (1.14Msps)
DAC: 2-channel 12-bit
Key Features Of STM32L485JCY6TR
Ultra-low power design
Supports multiple power saving modes, including:
Standby mode (0.29µA with RTC)
Stop mode (0.43µA with fast wake-up)
Run mode (down to 93µA/MHz)
Dynamic voltage regulation (DVS) to optimise power consumption under different loads
Rich peripheral interfaces
Communication interfaces: USB OTG, CAN 2.0B, I2C, SPI, UART, SAI (audio interface)
Timer: 16-bit / 32-bit timer, RTC (real-time clock), low-power timer (LPTIM)
LCD driver: supports segmented LCD display (supported by some STM32L4 series)
Enhanced safety features
Memory Protection Unit (MPU)
AES-128 hardware encryption engine (supported by some STM32L4 models)
True Random Number Generator (TRNG)
Industrial-grade reliability
Compliant with AEC-Q100 automotive electronics standard
