R5F111MFAFB Microcontroller MCU RL78/L1C Microcontroller IC 24MHz 16Bit MCU LQFP80

R5F111MFAFB Microcontroller MCU RL78/L1C Microcontroller IC 24MHz 16Bit MCU LQFP80

Product Description Of R5F111MFAFB

R5F111MFAFB is RL78/L1C microcontrollers, it have a built-in segment LCD driver and USB 2.0 function. Three LCD driving voltage generation methods (external resistance division, capacitive split, and internal voltage boost) are supported, corresponding to a variety of segment LCD panels.

Specification Of R5F111MFAFB

Features Of R5F111MFAFB

RL78 CPU core
- CISC architecture with 3-stage pipeline
- Minimum instruction execution time: Can be changed from high speed (0.04167 μs: @ 24 MHz operation with high-speed on-chip oscillator clock or PLL clock) to ultra-low speed (30.5 μs: @ 32.768 kHz operation with subsystem clock)
- Multiply/divide and multiply/accumulate instructions are supported.
- Address space: 1 Mbyte
- General-purpose registers: (8-bit register × 8) × 4 banks
- On-chip RAM: 8 to 16 KB
Code flash memory
- Code flash memory: 64 to 256 KB
- Block size: 1 KB
- Prohibition of block erase and rewriting (security function)
- On-chip debug function
- Self-programming (with boot swap function/flash shield window function)
Data flash memory
- Data flash memory: 8 KB
- Background operation (BGO): Instructions can be executed from the program memory while rewriting the data flash memory.
- Number of rewrites: 1,000,000 times (TYP.)
- Voltage of rewrites: VDD = 1.8 to 3.6 V
High-speed on-chip oscillator
- Select from 48 MHz, 24 MHz, 16 MHz, 12 MHz, 8 MHz, 6 MHz, 4 MHz, 3 MHz, 2 MHz, and 1 MHz
- High accuracy: ±1.0% (VDD = 1.8 to 3.6 V, TA = -20 to +85°C)

Applications Of R5F111MFAFB
Automated Meter Reader (AMR) Retrofit Module
EV Charger Wall Box with High-End HMI
Healthcare
Home appliances
USB
