S9KEAZ128AMLH Microcontroller MCU 48MHz Kinetis EA 32-Bit ARM Cortex-M4 MCU LQFP-64
S9KEAZ128AMLH Microcontroller MCU 48MHz Kinetis EA 32-Bit ARM Cortex-M4 MCU LQFP-64
Description
Part Number:
S9KEAZ128AMLH
Core::
ARM Cortex M0+
Program Memory Size::
128 KB
Data Bus Width::
32 Bit
ADC Resolution::
12 Bit
Maximum Clock Frequency::
48 MHz
S9KEAZ128AMLH Microcontroller MCU 48MHz Kinetis EA 32-Bit ARM Cortex-M4 MCU LQFP-64
Product Description Of S9KEAZ128AMLH
S9KEAZ128AMLH Kinetis® EA 32-bit Arm® Cortex® MCUs are targeted for a wide range of automotive and industrial applications requiring the highest level of quality and longevity support. The Kinetis EA series is an entry point to the broad Arm ecosystem and features:
A low-power Arm Cortex-M0+ core and 8–128 KB of embedded flash
Great EMC/ESD, high temperature, and low radiated emissions
Scalable, highly robust performance solution for cost-sensitive automotive applications
A broad set of reference designs, tools and application notes to help shorten design development and speed time-to-market
Specifications Of S9KEAZ128AMLH
ARM Cortex M0+
128 kB
32 bit
12 bit
48 MHz
71 I/O
16 kB
2.7 V
5.5 V
- 40 C
+ 125 C
DAC Resolution:
6 bit
Data RAM Type:
SRAM
Interface Type:
I2C, SPI, UART
Moisture Sensitive:
Yes
Number of ADC Channels:
16 Channel
Operating Supply Voltage:
3 V, 5 V
Unit Weight:
346.550 mg
Features Of S9KEAZ128AMLH
Performance
Up to 48 MHz Arm Cortex M0+ core
Single-cycle 32-bit x 32-bit multiplier
Memory
Up to 128K embedded flash
Up to 256 B EEPROM
Up to 16K RAM
Clocks
External Oscillator (OSC)
Internal Clock Source (ICS)
System functions
Power management module (PMC) with three power modes: Run, Wait, Stop
Low-voltage detection (LVD) with reset or interrupt, selectable trip points
Watchdog with independent clock source (WDOG)
Programmable cyclic redundancy check module (CRC)
Serial wire debug interface (SWD)
Aliased SRAM bitband region (BITBAND)
Bit manipulation engine (BME)
Communication interfaces
Up to two SPI modules
Up to three UART modules
Up to two IIC modules
Up to one CAN module
Multiple Timers
One 6-channel FlexTimer/PWM (FTM)
Up to two 2-channel FlexTimer/PWM (FTM)
One 2-channel periodic interrupt timer (PIT)
One pulse width timer (PWT)
One real-time clock (RTC)
Analog modules
One 16-channel 12-bit SAR ADC with internal bandgap reference channel, operation in Stop mode, optional hardware trigger (ADC)
Two analog comparators containing a 6-bit DAC and programmable reference input (ACMP)
Applications Of S9KEAZ128AMLH
Automotive
Diesel Engine Management
Electric Pumps
Motorcycle Engine Control Unit (ECU) and Small Engine Control
Industrial
3-Phase AC Induction Motor
Brushless DC Motor (BLDC) Control
Motion Control and Robotics
Motor Drives
Permanent Magnet Synchronous Motor (PMSM)
