STM32G071G8U6N Microcontroller MCU 32Bit Microcontrollers 64MHz STM32 Mainstream MCU

STM32G071G8U6N Microcontroller MCU 32Bit Microcontrollers 64MHz STM32 Mainstream MCU​

Product Description Of STM32G071G8U6N

STM32G071G8U6N mainstream microcontrollers is based on high-performance Arm® Cortex®-M0+ 32-bit RISC core operating at up to 64 MHz frequency. Offering a high level of integration, it is suitable for a wide range of applications in consumer, industrial and appliance domains and ready for the Internet of Things (IoT) solutions.

Specification Of STM32G071G8U6N

Features Of STM32G071G8U6N

Core: Arm® 32-bit Cortex®-M0+ CPU, frequency up to 64 MHz
-40°C to 85°C/105°C/125°C operating temperature
Memories
Up to 128 Kbytes of flash memory with protection and securable area
36 Kbytes of SRAM (32 Kbytes with HW parity check)
CRC calculation unit
Reset and power management
Voltage range: 1.7 V to 3.6 V
Low-power modes:Sleep, Stop, Standby, Shutdown
VBAT supply for RTC and backup registers
Clock management
4 to 48 MHz crystal oscillator
32 kHz crystal oscillator with calibration
Internal 16 MHz RC with PLL option (±1 %)
Internal 32 kHz RC oscillator (±5 %)
Up to 60 fast I/Os
All mappable on external interrupt vectors
Multiple 5 V-tolerant I/Os
7-channel DMA controller with flexible mapping
12-bit, 0.4 µs ADC (up to 16 ext. channels)
Up to 16-bit with hardware oversampling
Conversion range: 0 to 3.6V
Two 12-bit DACs, low-power sample-and-hold
Two fast low-power analog comparators, with programmable input and output, rail-to-rail
USB Type-C™ Power Delivery controller
