Product Description Of LPC5528JEV98
LPC5528JEV98 MCU is part of the EdgeVerse™ edge computing platform and further expands the world’s first general purpose Cortex-M33-based MCU series, offering significant advantages for developers, including pin-, software- and peripheral-compatibility for ease of use and accelerating time to market, while leveraging the cost-effective 40-nm NVM process technology.

LPC5528JEV98 is a mainstream family within the LPC5500 MCU, providing a perfect balance between security, performance efficiency and system integration for general embedded and industrial IoT markets. The LPC5528JEV98 combines the high-performance efficiency of the Cortex-M33 core with multiple high-speed interfaces, an integrated power management IC, and rich analog integration.

Specifications Of LPC5528JEV98

Features Of LPC5528JEV98
Arm Cortex-M33 Core
Running at a frequency of up to 150 MHz
Floating Point Unit (FPU) and Memory Protection Unit (MPU)
Arm Cortex M33 built-in Nested Vectored Interrupt Controller (NVIC)
Non-maskable Interrupt (NMI) input with a selection of sources
Serial Wire Debug with eight breakpoints and four watch points. Includes Serial Wire Output for enhanced debug capabilities
System tick timer
On-Chip Memory
Up to 512 kB on-chip flash program memory with flash accelerator and 512 byte page erase and write
Up to 512 kB total SRAM consisting of 32 kB SRAM on Code Bus, 192 kB SRAM on System Bus (192 kB is contiguous), 16 kB SRAM on System bus, and additional 16 kB USB SRAM on System Bus, which can be used by the USB interface or for general purpose use
Security Features
PRINCE module for real-time encryption of data being written to on-chip flash and decryption of encrypted flash data during read to allow asset protection
CASPER Crypto coprocessor is provided to enable hardware acceleration for various functions required for certain asymmetric cryptographic algorithms, such as, Elliptic Curve Cryptography (ECC)
AES-256 encryption/decryption engine
Secure Hash Algorithm (SHA2) module supporting secure boot with dedicated DMA controller
Physical Unclonable Function (PUF) using dedicated SRAM for silicon fingerprint. PUF can generate, store, and reconstruct key sizes from 64 to 4096 bits. Includes hardware for key extraction
128-bit unique device serial number for identification (UUID)
Secure GPIO
Random Number Generator (RNG)
Secure Boot support

Applications Of LPC5528JEV98
Automotive
Heating Ventilation and Air Conditioning (HVAC)
Consumer
Air Conditioning (AC)
Hearables
Major Home Appliances
Robotic Appliance
Small and Medium Appliances
Industrial
Automatic Vehicle Identification
Heat Meter
Industrial HMI
Smart Lighting
Smart Power Socket
Smart Watch and Wristband
Transport Ticketing
