STM8S005K6T6C Microcontroller MCU 8Bit Microcontroller IC Mainstream Value Line 8Bit MCU

STM8S005K6T6C Microcontroller MCU 8Bit Microcontroller IC Mainstream Value Line 8Bit MCU​

Product Description Of STM8S005K6T6C

STM8S005K6T6C is value line 8-bit microcontrollers offer 32 Kbytes of Flash program memory, plus 128 bytes of data EEPROM. STM8S005K6T6C provide the following benefits: performance, robustness, reduced system cost and short development cycles.

Specification Of STM8S005K6T6C

Features Of STM8S005K6T6C

Core
• Max fCPU: 16 MHz
• Advanced STM8 core with Harvard architecture and 3-stage pipeline
• Extended instruction set
Memories
• Medium-density Flash/EEPROM
– Program memory: 32 Kbytes of Flash memory; data retention 20 years at 55 °C after 100 cycles
– Data memory: 128 bytes true data EEPROM; endurance up to 100 k write/erase cycles
• RAM: 2 Kbytes
Clock, reset and supply management
• 2.95 V to 5.5 operating voltage
• Flexible clock control, 4 master clock sources
– Low-power crystal resonator oscillator
– External clock input
– Internal, user-trimmable 16 MHz RC
– Internal low-power 128 kHz RC
• Clock security system with clock monitor
• Power management
– Low-power modes (wait, active-halt, halt)
– Switch-off peripheral clocks individually
– Permanently active, low-consumption power-on and power-down reset Interrupt management
• Nested interrupt controller with 32 interrupts
• Up to 37 external interrupts on 6 vectors
Timers
• 2x 16-bit general purpose timers, with 2+3 CAPCOM channels (IC, OC or PWM)
• Advanced control timer: 16-bit, 4 CAPCOM channels, 3 complementary outputs, dead-time insertion and flexible synchronization
• 8-bit basic timer with 8-bit prescaler
• Auto wakeup timer
• Window and independent watchdog timers
Communications interfaces
• UART with clock output for synchronous operation, SmartCard, IrDA, LIN
• SPI interface up to 8 Mbit/s
• I2C interface up to 400 Kbit/s
Analog to digital converter (ADC)
• 10-bit ADC, ± 1 LSB ADC with up to 10 multiplexed channels, scan mode and analog watchdog
I/Os
• Up to 38 I/Os on a 48-pin package including 16 high-sink outputs
• Highly robust I/O design, immune against current injection
