STM8S207R8T6 Microcontroller MCU 8-Bit 24MHz Microcontroller With Integrated EEPROM

STM8S207R8T6 Microcontroller MCU 8-Bit 24MHz Microcontroller With Integrated EEPROM

Product Description Of STM8S207R8T6
STM8S207R8T6 performance line 8-bit microcontrollers offer from 32 to 128 Kbytes Flash program memory. They are referred to as high-density devices in the STM8S microcontroller family reference manual.

STM8S207R8T6 devices provide the following benefits: reduced system cost, performance robustness, short development cycles, and product longevity.

Specifications Of STM8S207R8T6

Features Of STM8S207R8T6
Core
Max fCPU: up to 24 MHz, 0 wait states @ fCPU≤ 16 MHz
Advanced STM8 core with Harvard architecture and 3-stage pipeline
Extended instruction set
Max 20 MIPS @ 24 MHz
Memories
Program: up to 128 Kbytes Flash; data retention 20 years at 55 °C after 10 kcycles
Data: up to 2 Kbytes true data EEPROM; endurance 300 kcycles
RAM: up to 6 Kbytes
Clock, reset and supply management
2.95 to 5.5 V operating voltage
Low power crystal resonator oscillator
External clock input
Internal, user-trimmable 16 MHz RC
Internal low power 128 kHz RC
Clock security system with clock monitor
Wait, active-halt, & halt low power modes
Peripheral clocks switched off individually
Permanently active, low consumption power-on and power-down reset
Interrupt management
Nested interrupt controller with 32 interrupts
Up to 37 external interrupts on 6 vectors
Timers
2x 16-bit general purpose timers, with 2+3 CAPCOM channels (IC, OC or PWM)
Advanced control timer: 16-bit, 4 CAPCOM channels, 3 complementary outputs, dead-time insertion and flexible synchronization
8-bit basic timer with 8-bit prescaler
Auto wakeup timer
Window watchdog, independent watchdog
Communications interfaces
High speed 1 Mbit/s active beCAN 2.0B
UART with clock output for synchronous operation - LIN master mode
UART with LIN 2.1 compliant, master/slave modes and automatic resynchronization
SPI interface up to 10 Mbit/s
I2C interface up to 400 Kbit/s
10-bit ADC with up to 16 channels
I/Os
Up to 68 I/Os on an 80-pin package including 18 high sink outputs
Highly robust I/O design, immune against current injection
Development support
Single wire interface module (SWIM) and debug module (DM)
96-bit unique ID key for each device
