HC32F176MATA-LQFP80 Microcontroller MCU 32Bit Microcontrollers 48MHz ARM Cortex M0 MCU

HC32F176MATA-LQFP80 Microcontroller MCU 32Bit Microcontrollers 48MHz ARM Cortex M0 MCU​

Product Description Of HC32F176MATA-LQFP80

HC32F176MATA-LQFP80 is 32-bit ARM Cortex-M0+ Microcontroller, operating frequency up to 48 MHz, this device features a flexible power management system and low power consumption.

Specification Of HC32F176MATA-LQFP80

Features Of HC32F176MATA-LQFP80

48MHz Cortex-M0+ 32-bit CPU platform
The HC32F176 series features a flexible power management system with low-power performance
128K bytes of Flash memory with write protection, supporting ISP, ICP, and IAP
16K bytes of RAM memory with parity check for enhanced system stability
Clock, crystal oscillator
– External high-speed crystal oscillator 4–32MHz
– External low-speed crystal oscillator 32.768KHz
– Internal high-speed clock 4/8/16/22.12/24 MHz
– Internal low-speed clock 32.8/38.4KHz
– PLL clock 8–48MHz
– Hardware support for internal and external clock calibration and monitoring
12-bit 1 Msps sampling high-speed high-precision SAR ADC with built-in follower, capable of measuring signals with high output impedance
1-channel 12-bit 500 Ksps DAC
Integrated with 1 multifunctional operational amplifier, which can serve as a DAC output buffer
Integrated 3-channel voltage comparators with 6-bit DAC and programmable comparison reference
Integrated low-voltage detector, configurable with 16-step comparison voltage, capable of monitoring port voltage and power supply voltage
SWD debugging solution, providing a full-featured debugger
Operating conditions: -40°C to 85°C, 1.8V to 5.5V
Package type: LQFP80
