STM32H750VBT6TR Microcontroller MCU 32Bit Microcontrollers 480MHz STM32H7 Series MCU
Product Attributes
| Attribute |
Value |
| Part Number |
STM32H750VBT6TR |
| Core |
ARM Cortex M7 |
| Program Memory Size |
128 kB |
| Data Bus Width |
32 bit |
| ADC Resolution |
3 x 16 bit |
| Number of I/Os |
82 I/O |
Product Description
STM32H750VBT6TR is based on the high-performance Arm® Cortex®-M7 32-bit RISC core operating at up to 480 MHz. The Cortex® -M7 core features a floating point unit (FPU) which supports Arm® double-precision (IEEE 754 compliant) and single-precision data-processing instructions and data types. STM32H750VBT6TR support a full set of DSP instructions and a memory protection unit (MPU) to enhance application security.
STM32H750VBT6TR incorporate high-speed embedded memories with a flash memory of 128 Kbytes, up to 1 Mbyte of RAM (including 192 Kbytes of TCM RAM, up to 864 Kbytes of user SRAM and 4 Kbytes of backup SRAM), as well as an extensive range of enhanced I/Os and peripherals connected to APB buses, AHB buses, 2x32-bit multi-AHB bus matrix and a multi layer AXI interconnect supporting internal and external memory access.
Specifications
| Parameter |
Value |
| Series |
STM32H7 |
| Core Processor |
ARM® Cortex®-M7 |
| Core Size |
32-Bit |
| Speed |
480MHz |
| Number of I/O |
82 |
| Program Memory Size |
128KB (128K x 8) |
| Program Memory Type |
FLASH |
| RAM Size |
1M x 8 |
| Voltage - Supply (Vcc/Vdd) |
1.62V ~ 3.6V |
| Data Converters |
A/D 16x16b; D/A 2x12b |
| Oscillator Type |
Internal |
| Operating Temperature |
-40°C ~ 85°C (TA) |
| Mounting Type |
Surface Mount |
| Supplier Device Package |
100-LQFP (14x14) |
| Package / Case |
100-LQFP |
Key Features
- Core: 32-bit Arm® Cortex®-M7 core with double-precision FPU and L1 cache: 16 Kbytes of data and 16 Kbytes of instruction cache; frequency up to 480 MHz, MPU, 1027 DMIPS/ 2.14 DMIPS/MHz (Dhrystone 2.1), and DSP instructions
- Memories: 128 Kbytes of flash memory, 1 Mbyte of RAM: 192 Kbytes of TCM RAM (inc. 64 Kbytes of ITCM RAM + 128 Kbytes of DTCM RAM for time critical routines), 864 Kbytes of user SRAM, and 4 Kbytes of SRAM in Backup domain
- Dual mode Quad-SPI memory interface running up to 133 MHz
- Flexible external memory controller with up to 32-bit data bus supporting SRAM, PSRAM, NOR flash, SDRAM/LPSDR SDRAM, and 8/16-bit NAND flash memories
- General-purpose input/outputs: Up to 168 I/O ports with interrupt capability
- 11 analog peripherals: 3× ADCs with 16-bit max. resolution (up to 36 channels, up to 3.6 MSPS), 1× temperature sensor, 2× 12-bit D/A converters (1 MHz), 2× ultra-low-power comparators, 2× operational amplifiers (7.3 MHz bandwidth), 1× digital filters for sigma delta modulator (DFSDM) with 8 channels/4 filters
Applications
- Industrial - Home, building, and city automation
- Personal electronics - Home entertainment
