STM32L031F6P6 Microcontroller MCU 32-Bit ARM Cortex-M0+ with 32MHz Clock and 32 kB Flash Memory

Large Image : STM32L031F6P6 Microcontroller MCU 32-Bit ARM Cortex-M0+ with 32MHz Clock and 32 kB Flash Memory

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	STM32L031F6P6

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	TSSOP-20
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

STM32L031F6P6 Microcontroller MCU 32-Bit ARM Cortex-M0+ with 32MHz Clock and 32 kB Flash Memory

Description

Part Number:	STM32L031F6P6	Core::	ARM Cortex M0+
Program Memory Size::	32 KB	Data Bus Width::	32 Bit
ADC Resolution::	12 Bit	Maximum Clock Frequency::	32 MHz
Highlight:	32-Bit Microcontroller MCU , 32MHz ARM Cortex-M0+ , 32 kB Flash STM32L031F6P6

STM32L031F6P6 Microcontroller MCU 32-Bit 32MHz ARM Cortex-M0+

Product Overview

The STM32L031F6P6 is an access line ultra-low-power microcontroller incorporating the high-performance ARM® Cortex®-M0+ 32-bit RISC core operating at 32 MHz. It features high-speed embedded memories (up to 32KB Flash, 1KB EEPROM, and 8KB RAM) along with enhanced I/Os and peripherals. Designed for power efficiency, it offers multiple low-power modes and clock source options.

Key Specifications

Core Processor	ARM® Cortex®-M0+
Core Size	32-Bit
Speed	32MHz
Connectivity	I2C, IrDA, LINbus, SPI, UART/USART
Peripherals	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Number of I/O	15
Program Memory Size	32KB (32K x 8)
Program Memory Type	FLASH
EEPROM Size	1K x 8
RAM Size	8K x 8
Voltage Supply	1.8V ~ 3.6V
Data Converters	A/D 10x12b
Oscillator Type	Internal
Operating Temperature	-40°C ~ 85°C (TA)

Key Features

Ultra-low-power platform (1.65V to 3.6V power supply)
0.25 μA Standby mode (2 wakeup pins)
0.38 μA Stop mode (16 wakeup lines)
0.68 μA Stop mode with RTC + 8KB RAM retention
76 μA/MHz in Run mode
5 μs wakeup time (from Flash memory)
41 μA 12-bit ADC conversion (at 10ksps)
ARM® 32-bit Cortex®-M0+ core (0.95 DMIPS/MHz)
Multiple clock sources including crystal oscillators and internal RC
Up to 38 fast I/Os (31 I/Os 5V tolerant)
Rich analog peripherals including 12-bit ADC and comparators
Multiple communication interfaces (USART, SPI, I2C)
8 timers including ultra-low-power timer and watchdogs
