PIC18F45J10T-I/PT Microcontroller MCU High-Performance 8-Bit 40MHz RISC Microcontrollers
The PIC18F45J10T-I/PT is ideal for applications requiring low cost, high speed, and enhanced serial communication peripherals. This microcontroller operates at 40MHz with 3V supply and features an enhanced USART with LIN capability, two synchronous serial ports with address masking for I2C, making it a cost-effective general purpose solution for designs requiring 1k Flash endurance, emulated EEPROM, and external crystal or clock source.
Specifications
| Core Processor |
PIC |
| Core Size |
8-Bit |
| Speed |
40MHz |
| Connectivity |
I2C, SPI, UART/USART |
| Peripherals |
Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O |
32 |
| Program Memory Size |
32KB (16K x 16) |
| Program Memory Type |
FLASH |
| RAM Size |
1K x 8 |
| Voltage - Supply (Vcc/Vdd) |
2.7V ~ 3.6V |
| Data Converters |
A/D 13x10b |
| Oscillator Type |
Internal |
| Operating Temperature |
-40°C ~ 85°C (TA) |
Special Microcontroller Features
- Operating Voltage Range: 2.0V to 3.6V
- 5.5V Tolerant Input (digital pins only)
- On-Chip 2.5V Regulator
- 4x Phase Lock Loop (PLL) available for Crystal and Internal Oscillators
- Self-Programmable under Software Control
- Low-Power, High-Speed CMOS Flash Technology
- C Compiler Optimized Architecture with optional extended instruction set
- Priority Levels for Interrupts
- 8 x 8 Single-Cycle Hardware Multiplier
- Extended Watchdog Timer (WDT) with programmable period from 4 ms to 131s
- Single-Supply In-Circuit Serial Programming™ (ICSP™) via Two Pins
- In-Circuit Debug (ICD) with Three Breakpoints via Two Pins
- Power-Managed modes with Clock Switching
Flexible Oscillator Structure
- Two Crystal modes, up to 40 MHz
- Two External Clock modes, up to 40 MHz
- Internal 31 kHz Oscillator
- Secondary Oscillator using Timer1 @ 32 kHz
- Two-Speed Oscillator Start-up
- Fail-Safe Clock Monitor for safe shutdown if peripheral clock stops
Peripheral Highlights
- High-Current Sink/Source 25 mA/25 mA (PORTB and PORTC)
- Three Programmable External Interrupts
- Four Input Change Interrupts
- One Capture/Compare/PWM (CCP) module
- One Enhanced Capture/Compare/PWM (ECCP) module with multiple PWM outputs
- Two Master Synchronous Serial Port (MSSP) modules
- One Enhanced Addressable USART module supporting RS-485, RS-232 and LIN/J2602
- 10-Bit, up to 13-Channel Analog-to-Digital Converter module
- Dual Analog Comparators with Input Multiplexing
