R5F10RLCAFB 24MHz RL78/L12 Microcontroller MCU with 32KB Program Memory and 2KB Data Flash in LFQFP64 Package

R5F10RLCAFB 24MHz RL78/L12 Microcontroller MCU with 32KB Program Memory and 2KB Data Flash in LFQFP64 Package
R5F10RLCAFB 24MHz RL78/L12 Microcontroller MCU with 32KB Program Memory and 2KB Data Flash in LFQFP64 Package R5F10RLCAFB 24MHz RL78/L12 Microcontroller MCU with 32KB Program Memory and 2KB Data Flash in LFQFP64 Package

Large Image :  R5F10RLCAFB 24MHz RL78/L12 Microcontroller MCU with 32KB Program Memory and 2KB Data Flash in LFQFP64 Package

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: R5F10RLCAFB
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: LFQFP-64
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

R5F10RLCAFB 24MHz RL78/L12 Microcontroller MCU with 32KB Program Memory and 2KB Data Flash in LFQFP64 Package

Description
Part Number: R5F10RLCAFB Series: RL78/L12
Program Memory: 32KB Data Flash: 2KB
Supply Voltage: 1.6V ~ 5.5V I/O Ports: 47
Highlight:

24MHz RL78/L12 Microcontroller

,

32KB Program Memory MCU

,

2KB Data Flash Microcontroller

R5F10RLCAFB Microcontroller MCU 24MHz RL78/L12 Microcontroller IC 16-Bit MCU LFQFP64
Product Description
The R5F10RLCAFB RL78/L12 microcontroller features a built-in segment LCD driver with three voltage generation methods (external resistance division, capacitive split, and internal voltage boost) to support various segment LCD panels. It achieves ultra-low current consumption with external resistance division (1.60 μA), internal voltage boost (1.19 μA), and capacitive split (0.68 µA).
Specifications
Series RL78/L12
Core Processor RL78
Core Size 16-Bit
Speed 24MHz
Connectivity CSI, I2C, LINbus, UART/USART
Peripherals DMA, LCD, LVD, POR, PWM, WDT
Number of I/O 47
Program Memory Size 32KB (32K x 8)
Program Memory Type FLASH
EEPROM Size 2K x 8
RAM Size 1.5K x 8
Voltage - Supply (Vcc/Vdd) 1.6V ~ 5.5V
Data Converters A/D 10x10b
Oscillator Type Internal
Operating Temperature -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Supplier Device Package 64-LFQFP (10x10)
Package / Case 64-LQFP
Key Features
  • Ultra-Low Power Technology: 1.6 V to 5.5 V operation from single supply with multiple low-power modes
  • 16-bit RL78 CPU Core: Delivers 31 DMIPS at 24 MHz with efficient instruction execution
  • Code Flash Memory: 8 KB to 32 KB density with 1 KB block size and protection features
  • Data Flash Memory: 2 KB size with background operation and high erase cycles
  • RAM: 1 KB and 1.5 KB size options with back-up retention in all modes
Applications
Programmable Radiator Thermostat
Healthcare
Home Appliance
Office
Security
