PIC16F946-I/PT 8-Bit Microcontroller MCU with 20MHz Speed LCD Driver and nanoWatt Technology

PIC16F946-I/PT 8-Bit Microcontroller MCU with 20MHz Speed LCD Driver and nanoWatt Technology
PIC16F946-I/PT 8-Bit Microcontroller MCU with 20MHz Speed LCD Driver and nanoWatt Technology PIC16F946-I/PT 8-Bit Microcontroller MCU with 20MHz Speed LCD Driver and nanoWatt Technology

Large Image :  PIC16F946-I/PT 8-Bit Microcontroller MCU with 20MHz Speed LCD Driver and nanoWatt Technology

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: PIC16F946-I/PT
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TQFP-64
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

PIC16F946-I/PT 8-Bit Microcontroller MCU with 20MHz Speed LCD Driver and nanoWatt Technology

Description
Part Number: PIC16F946-I/PT Core:: PIC16
Program Memory Size:: 14 KB Data RAM Size:: 336 B
Maximum Clock Frequency:: 20 MHz ADC Resolution:: 10 Bit
Highlight:

20MHz Microcontroller MCU

,

LCD Driver 8-Bit Microcontroller

,

nanoWatt Technology PIC16F946-I/PT

PIC16F946-I/PT Microcontroller MCU
8-Bit 20MHz CMOS Microcontroller With LCD Driver And nanoWatt Technology
Product Overview
The PIC16F946-I/PT is a high-performance PIC® 16F 8-bit microcontroller featuring a 20MHz CMOS architecture with integrated LCD driver and advanced nanoWatt power management technology.
Technical Specifications
Specification Details
Core Processor PIC
Core Size 8-Bit
Speed 20MHz
Connectivity I2C, SPI, UART/USART
Peripherals Brown-out Detect/Reset, LCD, POR, PWM, WDT
Number of I/O 53
Program Memory Size 14KB (8K x 14)
Program Memory Type FLASH
EEPROM Size 256 x 8
RAM Size 336 x 8
Voltage Supply (Vcc/Vdd) 2V ~ 5.5V
Data Converters A/D 8x10b
Oscillator Type Internal
Operating Temperature -40°C ~ 85°C (TA)
Key Features
High-Performance RISC CPU:
  • Only 35 instructions to learn
    • All single-cycle instructions except branches
  • Operating speed: DC - 20 MHz oscillator/clock input, DC - 200 ns instruction cycle
  • Program Memory Read (PMR) capability
  • Interrupt capability
  • 8-level deep hardware stack
  • Direct, Indirect and Relative Addressing modes
Special Microcontroller Features:
  • Precision Internal Oscillator: Factory calibrated to ±1%, software selectable frequency range of 8 MHz to 125 kHz
  • Software tunable with Two-Speed Start-up mode
  • External Oscillator fail detect for critical applications
  • Clock mode switching during operation for power savings
  • Software selectable 31 kHz internal oscillator
  • Power-Saving Sleep mode
  • Wide operating voltage range (2.0V-5.5V)
  • Industrial and Extended temperature range
  • Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
  • Brown-out Reset (BOR) with software control option
  • Enhanced Low-Current Watchdog Timer (WDT) with on-chip oscillator
  • Multiplexed Master Clear with pull-up/input pin
  • Programmable code protection
  • High-Endurance Flash/EEPROM cell: 100,000 write Flash endurance, 1,000,000 write EEPROM endurance
Low-Power Features:
  • Standby Current: <100 nA @ 2.0V, typical
  • Operating Current: 11 μA @ 32 kHz, 2.0V, typical
  • Watchdog Timer Current: 1 μA @ 2.0V, typical
Peripheral Features:
  • Liquid Crystal Display module with up to 60/96/168 pixel drive capability
  • Up to 24/35/53 I/O pins and 1 input-only pin
  • High-current source/sink for direct LED drive
  • Interrupt-on-change pin
  • Individually programmable weak pull-ups
  • In-Circuit Serial Programming™ (ICSP™) via two pins
  • Analog comparator module with two analog comparators
  • 10-bit A/D Converter with up to 8 channels
  • Timer0: 8-bit timer/counter with 8-bit programmable prescaler
  • Enhanced Timer1: 16-bit timer/counter with prescaler
  • Timer2: 8-bit timer/counter with 8-bit period register
  • Addressable Universal Synchronous Asynchronous Receiver Transmitter (AUSART)
  • Up to 2 Capture, Compare, PWM modules
  • Synchronous Serial Port (SSP) with I2C™
