LPC1114FHI33 32-Bit ARM Cortex-M0 Microcontroller MCU with 50MHz Speed and 32KB Flash Memory

Large Image : LPC1114FHI33 32-Bit ARM Cortex-M0 Microcontroller MCU with 50MHz Speed and 32KB Flash Memory

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	LPC1114FHI33

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	HVQFN-33
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10000 Pieces per Day

Contact Now

LPC1114FHI33 32-Bit ARM Cortex-M0 Microcontroller MCU with 50MHz Speed and 32KB Flash Memory

Description

Part Number:	LPC1114FHI33	Core::	ARM Cortex M0
Program Memory Size::	32 KB	Data Bus Width::	32 Bit
ADC Resolution::	8 Bit	Maximum Clock Frequency::	50 MHz
Highlight:	32-Bit Microcontroller MCU , 50MHz Speed ARM Cortex-M0 MCU , 32KB Flash Memory LPC1114FHI33

LPC1114FHI33 32-Bit ARM Cortex-M0 Microcontroller

The LPC1114FHI33 is an ARM Cortex-M0 based, low-cost 32-bit microcontroller designed for 8/16-bit microcontroller applications. It offers superior performance, low power consumption, simple instruction set, and efficient memory addressing with reduced code size compared to existing 8/16-bit architectures.

Product Specifications

Core Processor	ARM® Cortex®-M0
Core Size	32-Bit
Speed	50MHz
Connectivity	I2C, SPI, UART/USART
Peripherals	Brown-out Detect/Reset, POR, WDT
Number of I/O	28
Program Memory Size	32KB (32K x 8)
Program Memory Type	FLASH
RAM Size	8K x 8
Voltage Supply	1.8V ~ 3.6V
Data Converters	A/D 8x10b
Oscillator Type	Internal
Operating Temperature	-40°C ~ 85°C (TA)

Key Features

System Architecture

Arm Cortex-M0 processor running at up to 50 MHz
Built-in nested vectored interrupt controller (NVIC)
Non-maskable interrupt (NMI) input
Serial wire debug capability
System tick timer

Memory Features

Up to 64 KB on-chip flash programming memory
Up to 8 KB SRAM
In-system programming (ISP) and In-application programming (IAP) via on-chip bootloader

Digital Peripherals

Up to 42 General purpose I/O (GPIO) pins with configurable pull-up/pull-down resistors
GPIO pins support edge and level sensitive interrupt sources
High-current output driver (20 mA) on one pin
Four general purpose counter/timers with capture inputs and match outputs
Programmable windowed WDT

Analog Peripherals

10/12-bit ADC with up to 2 Msamples/s and up to eight channels

Serial Interfaces

Up to 3 UARTs with fractional baud rate generation and RS-485 support
Up to 2 SPI controllers with SSP features and multi-protocol capabilities
I²C-bus interface supporting full specification with data rate up to 1 Mbit/s

Clock Generation

12 MHz internal RC oscillator with 1% accuracy
Crystal oscillator supporting 1 MHz to 25 MHz range
Programmable watchdog oscillator (9.4 kHz to 2.3 MHz)
PLL for maximum CPU rate operation
Clock output function with divider

Power Management

Integrated PMU for minimized power consumption
Three reduced power modes: Sleep, Deep-sleep, and Deep power-down
Processor wake-up from Deep-sleep mode via dedicated start logic
Power-On Reset (POR) and Brownout detect with multiple thresholds

Target Applications

eMetering systems, Lighting control, Alarm and security systems, White goods and home appliances
