STM32F103RCT6 32-Bit Microcontroller with ARM Cortex-M3 Core, 72MHz Speed, 256KB Flash Memory, and 12-bit ADC

Large Image : STM32F103RCT6 32-Bit Microcontroller with ARM Cortex-M3 Core, 72MHz Speed, 256KB Flash Memory, and 12-bit ADC

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	STM32F103RCT6

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	LQFP-64
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

STM32F103RCT6 32-Bit Microcontroller with ARM Cortex-M3 Core, 72MHz Speed, 256KB Flash Memory, and 12-bit ADC

Description

Part Number:	STM32F103RCT6	Core::	ARM Cortex M3
Program Memory Size::	256 KB	Data Bus Width::	32 Bit
ADC Resolution::	12 Bit	Maximum Clock Frequency::	72 MHz
Highlight:	72MHz STM32F103RCT6 Microcontroller , 256KB Flash Memory ARM Cortex-M3 MCU , 12-bit ADC 32-Bit Microcontroller

STM32F103RCT6 Microcontroller MCU 32-Bit 72MHz ARM Cortex-M3

Product Overview

The STM32F103RCT6 performance line family incorporates the high-performance ARM® Cortex®-M3 32-bit RISC core operating at 72 MHz frequency, high-speed embedded memories (Flash memory up to 512 Kbytes and SRAM up to 64 Kbytes), and an extensive range of enhanced I/Os and peripherals connected to two APB buses. All devices offer three 12-bit ADCs, four general-purpose 16-bit timers plus two PWM timers, as well as standard and advanced communication interfaces: up to two I2Cs, three SPIs, two I2Ss, one SDIO, five USARTs, USB and CAN.

Technical Specifications

Core Processor	ARM® Cortex®-M3
Core Size	32-Bit
Speed	72MHz
Connectivity	CANbus, I2C, IrDA, LINbus, SPI, UART/USART, USB
Peripherals	DMA, Motor Control PWM, PDR, POR, PVD, PWM, Temp Sensor, WDT
Number of I/O	51
Program Memory Size	256KB (256K x 8)
Program Memory Type	FLASH
RAM Size	48K x 8
Voltage Supply	2V ~ 3.6V
Data Converters	A/D 16x12b; D/A 2x12b
Oscillator Type	Internal
Operating Temperature	-40°C ~ 85°C (TA)

Key Features

ARM® 32-bit Cortex®-M3 CPU with 72 MHz maximum frequency
1.25 DMIPS/MHz (Dhrystone 2.1) performance at 0 wait state memory access
Single-cycle multiplication and hardware division
256 to 512 Kbytes of Flash memory, up to 64 Kbytes of SRAM
Flexible static memory controller with 4 Chip Select
LCD parallel interface with 8080/6800 modes
2.0 to 3.6 V application supply and I/Os
Multiple power management features: POR, PDR, programmable voltage detector (PVD)
Comprehensive clock system with multiple oscillator options
Low power modes: Sleep, Stop and Standby
3 × 12-bit, 1 μs A/D converters (up to 21 channels)
2 × 12-bit D/A converters
12-channel DMA controller supporting multiple peripherals
Debug mode with Serial wire debug (SWD) & JTAG interfaces
Up to 112 fast I/O ports with 5 V-tolerant capability
Up to 11 timers including motor control PWM with dead-time generation
Up to 13 communication interfaces including USB 2.0 full speed and CAN
CRC calculation unit and 96-bit unique ID
ECOPACK® environmentally friendly packages

Applications

Industrial applications, home and professional appliances
