ATSAMD21G18A-AU Microcontroller MCU
High-performance 32-bit microcontroller featuring a 48MHz ARM Cortex-M0+ processor with 256KB Flash and 32KB SRAM memory. This low-power MCU offers comprehensive connectivity options and advanced peripherals for industrial applications.
Product Overview
The ATSAMD21G18A-AU is a low-power microcontroller utilizing the 32-bit Arm® Cortex®-M0+ processor. Available in 48-pin configuration with up to 256 KB Flash and 32 KB of SRAM, it operates at a maximum frequency of 48 MHz and achieves 2.46 CoreMark/MHz. Designed for seamless migration within the product series, it features identical peripheral modules, hex compatible code, identical linear address map, and pin compatible migration paths.
Technical Specifications
| Series | SAM D21G, Functional Safety (FuSa) |
| Core Processor | ARM® Cortex®-M0+ |
| Core Size | 32-Bit |
| Speed | 48MHz |
| Connectivity | I2C, LINbus, SPI, UART/USART, USB |
| Peripherals | Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT |
| Number of I/O | 38 |
| Program Memory Size | 256KB (256K x 8) |
| Program Memory Type | FLASH |
| RAM Size | 32K x 8 |
| Voltage Supply | 1.62V ~ 3.6V |
| Data Converters | A/D 14x12b; D/A 1x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 48-TQFP (7x7) |
| Package / Case | 48-TQFP |
Key Features
Single-cycle hardware multiplier
Micro Trace Buffer
256KB in-system self-programmable Flash
32KB SRAM Memory
Power-on reset (POR) and brown-out detection (BOD)
Internal and external clock options with 48MHz Digital Frequency Locked Loop (DFLL48M)
External Interrupt Controller (EIC) with 16 external interrupts
Two-pin Serial Wire Debug (SWD) programming interface
Drop-in compatible with SAM D20
Idle and standby sleep modes with SleepWalking peripherals
12-channel Direct Memory Access Controller (DMAC)
12-channel Event System
Multiple timer/counter configurations
Synchronized PWM pattern generation
Deterministic fault protection and configurable dead-time
Dithering for increased resolution
32-bit Real Time Counter (RTC) with clock/calendar
Watchdog Timer (WDT)
CRC-32 generator
Embedded device function with eight endpoints
Comprehensive communication interfaces
Advanced analog capabilities
10-bit, 350ksps Digital-to-Analog Converter (DAC)
Two Analog Comparators (AC) with window compare
256-channel capacitive touch and proximity sensing
38 GPIO pins
