STM32F301K8T7 32-Bit Microcontroller IC with 72 MHz ARM Cortex M4 Core and 8 Channel ADC

Large Image : STM32F301K8T7 32-Bit Microcontroller IC with 72 MHz ARM Cortex M4 Core and 8 Channel ADC

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	STM32F301K8T7

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	LQFP-32
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

STM32F301K8T7 32-Bit Microcontroller IC with 72 MHz ARM Cortex M4 Core and 8 Channel ADC

Description

Part Number:	STM32F301K8T7	Number Of I/Os:	10 I/O
Maximum Clock Frequency:	72 MHz	Core Processor:	ARM Cortex M4
Number Of ADC Channels:	8 Channel	Data RAM Size:	16 KB
Highlight:	72 MHz Microcontroller MCU , ARM Cortex M4 32-Bit Microcontroller IC , 8 Channel ADC STM32 Mainstream Mixed Signals MCU

STM32F301K8T7 Microcontroller MCU

32-Bit Microcontroller IC STM32 Mainstream Mixed Signals MCU

Product Overview

The STM32F301K8T7 is a high-performance 32-bit microcontroller based on the Arm® Cortex®-M4 RISC core, operating at frequencies up to 72 MHz with an integrated floating point unit (FPU). This mainstream mixed-signals MCU features high-speed embedded memories including up to 64 KB Flash and 16 KB SRAM, along with extensive enhanced I/Os and peripherals.

Technical Specifications

Parameter	Specification
Core Processor	ARM® Cortex®-M4
Core Size	32-Bit
Speed	72MHz
Connectivity	I2C, IrDA, LINbus, SPI, UART/USART
Peripherals	DMA, I2S, POR, PWM, WDT
Number of I/O	25
Program Memory Size	64KB (64K x 8)
Program Memory Type	FLASH
RAM Size	16K x 8
Voltage Supply	2V ~ 3.6V
Data Converters	A/D 8x12b; D/A 1x12b
Oscillator Type	Internal
Operating Temperature	-40°C ~ 105°C (TA)
Mounting Type	Surface Mount
Package / Case	32-LQFP (7x7)

Key Features

Arm® 32-bit Cortex®-M4 CPU with FPU (72 MHz max.), single-cycle multiplication and HW division, DSP instruction
32 to 64 Kbytes of Flash memory with 16 Kbytes of SRAM on data bus
CRC calculation unit for data integrity
Advanced power management with low-power modes: Sleep, Stop, and Standby
Comprehensive clock management with multiple oscillator options
Up to 51 fast I/O ports, all mappable on external interrupt vectors
7-channel DMA controller supporting timers, ADCs, SPIs, I2Cs, USARTs and DAC
1 × ADC 0.20 μs (up to 15 channels) with selectable resolution
Temperature sensor and 1 x 12-bit DAC channel
Three fast rail-to-rail analog comparators and 1 operational amplifier
Up to 18 capacitive sensing channels supporting touchkey, linear and rotary sensors
Up to 9 timers including advanced-control, basic, and watchdog timers
Calendar RTC with alarm and periodic wakeup functionality
Multiple communication interfaces: Three I2Cs, up to 3 USARTs, up to two SPIs with I2S
Infrared transmitter and serial wire debug (SWD), JTAG interfaces
96-bit unique ID for device identification
