SAK-XC2234L-20F66LR AA Microcontroller MCU Single-Chip Microcontroller with 32-Bit Performance, 1 MHz to 100 MHz Frequency Range, and 1.8 V to 3.6 V Operating Voltage

SAK-XC2234L-20F66LR AA Microcontroller MCU Single-Chip Microcontroller With 32-Bit Performance

Product Description Of SAK-XC2234L-20F66LR AA
SAK-XC2234L-20F66LR AA is a part of the XC2000 Family of full feature singlechip CMOS microcontrollers. These devices extend the functionality and performance of the C166 Family in terms of instructions (MAC unit), peripherals, and speed. They combine high CPU performance (up to 80 million instructions per second) with extended peripheral functionality and enhanced IO capabilities. Optimized peripherals can be
adapted flexibly to meet the application requirements. These derivatives utilize clock generation via PLL and internal or external clock sources. On-chip memory modules include program Flash, program RAM, and data RAM.

Specifications Of SAK-XC2234L-20F66LR AA
Package: 6-pin LCC
Frequency range: 1 MHz to 100 MHz
Frequency tolerance: ±20 ppm
Operating voltage: 1.8 V to 3.6 V
Operating temperature: -40°C to +85°C
Start-up time: Less than 2 ms
Load capacitance: No external load capacitance
Output type: CMOS output
Power consumption: Maximum 2 mA

Features Of SAK-XC2234L-20F66LR AA
High-precision frequency output: This device offers a frequency tolerance of ±20ppm, maintaining high frequency stability under various operating conditions.
Compact packaging: Utilising a 6-pin LCC package, its compact dimensions make it highly suitable for applications with stringent space constraints.
Low-power design: Its typical operating current is merely a few milliamps, making it suitable for battery-powered portable devices.
Wide operating voltage range: Supports a broad input voltage range from 1.8V to 3.6V, enhancing the chip's adaptability.
Rapid start-up time: The chip achieves stable operation within 2 milliseconds post-power-up.
Robust interference resistance: Integrated internal filtering circuits effectively mitigate external electromagnetic interference affecting the output signal.
CMOS output compatibility: Provides standard CMOS output signals for direct interfacing with other digital circuits.

Applications Of SAK-XC2234L-20F66LR AA
Consumer electronics: Devices requiring high-precision clock sources, such as smartphones, tablets, and digital cameras.
Industrial automation: Used for system clock or synchronisation signal generation on industrial control boards.
Communication equipment: Provides stable reference clocks for routers, switches, and other network devices.
Medical instruments: Timing modules in equipment such as patient monitors and ultrasound devices.
Automotive electronics: Suitable for applications including car navigation systems and infotainment systems.
