S912XET256W1MAL 50MHz 16-Bit HCS12X Microcontroller MCU with 256KB Flash and AEC-Q100 Compliance

S912XET256W1MAL 50MHz 16-Bit HCS12X Microcontroller MCU with 256KB Flash and AEC-Q100 Compliance
S912XET256W1MAL 50MHz 16-Bit HCS12X Microcontroller MCU with 256KB Flash and AEC-Q100 Compliance S912XET256W1MAL 50MHz 16-Bit HCS12X Microcontroller MCU with 256KB Flash and AEC-Q100 Compliance

Large Image :  S912XET256W1MAL 50MHz 16-Bit HCS12X Microcontroller MCU with 256KB Flash and AEC-Q100 Compliance

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: S912XET256W1MAL
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: LQFP-112
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

S912XET256W1MAL 50MHz 16-Bit HCS12X Microcontroller MCU with 256KB Flash and AEC-Q100 Compliance

Description
Part Number: S912XET256W1MAL Core: HCS12X
ADC Resolution: 2 X 8 Bit/10 Bit/12 Bit Number Of I/Os: 91 I/O
I/O Voltage: 3.13 V To 5.5 V Operating Temperature: -40°C ~ 125°C (TA)
Highlight:

50MHz HCS12X Microcontroller

,

256KB Flash Microcontroller MCU

,

AEC-Q100 Compliant 16-Bit Microcontroller

S912XET256W1MAL Microcontroller MCU
50MHz 16-Bit HCS12X Microcontroller IC in LQFP112 Package
Product Overview
The S912XET256W1MAL is an HCS12X series 16-bit microcontroller featuring a 50MHz operating frequency, 256KB Flash memory, and an 112-pin LQFP package. Designed for automotive and industrial control applications, it complies with AEC-Q100 standards with an operating voltage range of 1.72V to 5.5V and temperature range of -40°C to 125°C.
Technical Specifications
Parameter Specification
Core Processor HCS12X
Core Size 16-Bit
Speed 50MHz
Connectivity CANbus, EBI/EMI, I2C, IrDA, SCI, SPI
Peripherals LVD, POR, PWM, WDT
Number of I/O 91
Program Memory Size 256KB (256K x 8)
Program Memory Type FLASH
EEPROM Size 4K x 8
RAM Size 16K x 8
Voltage Supply 1.72V ~ 5.5V
Data Converters A/D 16x12b
Oscillator Type External
Operating Temperature -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Supplier Device Package 112-LQFP (20x20)
Package / Case 112-LQFP
Key Features
  • Performance and Storage: 50MHz HCS12X core, 256KB Flash supporting in-system programming, 16KB RAM and 4KB EEPROM to meet medium-scale control requirements.
  • Analogue and Peripherals: 16-channel 12-bit ADC, multi-channel PWM, CAN/LIN communication, SCI/SPI/I2C, IrDA, EBI/EMI expansion, integrated LVD/POR/WDT for enhanced system reliability.
  • Automotive-grade Reliability: AEC-Q100 Grade 1 compliant, with wide temperature and voltage range design, suitable for demanding applications such as body control, multiplexing, and industrial drives.
  • Package and Process: 112-pin LQFP (20×20mm), 0.65mm pin pitch, surface-mount technology, compatible with automated production lines and high-density layouts.
