STM8L052C6T6TR Microcontroller MCU 8-Bit 16MHz Ultra-low-power EnergyLite Microcontroller

STM8L052C6T6TR Microcontroller MCU 8-Bit 16MHz Ultra-low-power EnergyLite Microcontroller
STM8L052C6T6TR Microcontroller MCU 8-Bit 16MHz Ultra-low-power EnergyLite Microcontroller STM8L052C6T6TR Microcontroller MCU 8-Bit 16MHz Ultra-low-power EnergyLite Microcontroller

Large Image :  STM8L052C6T6TR Microcontroller MCU 8-Bit 16MHz Ultra-low-power EnergyLite Microcontroller

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: STM8L052C6T6TR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 48-LQFP
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

STM8L052C6T6TR Microcontroller MCU 8-Bit 16MHz Ultra-low-power EnergyLite Microcontroller

Description
Part Number: STM8L052C6T6TR Core Processor: STM8L
Core Size: 8-Bit Speed: 16MHz
Connectivity: I2C, IrDA, SPI, UART/USART Unit Weight:: 180 Mg
Highlight:

8-Bit Microcontroller MCU

,

16MHz STM8L052C6T6TR

,

Ultra-low-power EnergyLite Microcontroller

The STM8L052C6T6TR is a medium-density value line microcontroller from the STM8L ultra-low-power 8-bit family. This EnergyLite microcontroller features an enhanced STM8 CPU core that delivers up to 16 MIPS at 16 MHz while maintaining CISC architecture advantages with improved code density, 24-bit linear addressing space, and optimized low-power operation architecture.
Technical Specifications
Parameter Specification
Core Size 8-Bit
Speed 16MHz
Connectivity I2C, IrDA, SPI, UART/USART
Peripherals Brown-out Detect/Reset, DMA, IR, LCD, POR, PWM, WDT
Number of I/O 41
Program Memory Size 32KB (32K x 8)
Program Memory Type FLASH
EEPROM Size 256 x 8
RAM Size 2K x 8
Voltage Supply (Vcc/Vdd) 1.8V ~ 3.6V
Data Converters A/D 25x12b
Oscillator Type Internal
Operating Temperature -40°C ~ 85°C (TA)
Key Features
Operating Conditions
  • Operating power supply: 1.8 V to 3.6 V
  • Temperature range: -40 °C to 85 °C
Low-Power Features
  • Five low-power modes: Wait, Low-power run (5.1 μA), Low-power wait (3 μA), Active-halt with full RTC (1.3 μA), Halt (350 nA)
  • Consumption: 195 μA/MHz + 440 μA
  • Ultra-low leakage per I/O: 50 nA
  • Fast wakeup from Halt: 4.7 μs
Advanced STM8 Core
  • Harvard architecture and 3-stage pipeline
  • Max frequency 16 MHz, 16 CISC MIPS peak
  • Up to 40 external interrupt sources
Reset and Supply Management
  • Low-power, ultra-safe BOR reset with five selectable thresholds
  • Ultra-low-power POR/PDR
  • Programmable voltage detector (PVD)
Clock Management
  • 32 kHz and 1 to 16 MHz crystal oscillator
  • Internal 16 MHz factory-trimmed RC
  • Internal 38 kHz low consumption RC
  • Clock security system
Additional Features
  • Low-power RTC with BCD calendar and alarm interrupt
  • Auto-wakeup from Halt with periodic interrupt
  • LCD: up to 4x28 segments with step-up converter
  • 32 KB Flash program memory and 256 bytes data EEPROM with ECC, RWW
  • Flexible write and read protection modes
  • 2 Kbytes of RAM
  • Four-channel DMA supporting ADC, SPI, I2C, USART, timers
  • One channel for memory-to-memory transfer
  • 12-bit ADC up to 1 Msps/25 channels with internal reference voltage
  • Multiple timers including 16-bit and 8-bit variants
  • Two watchdogs: Window and Independent
  • Beeper timer with 1-, 2- or 4-kHz frequencies
  • Synchronous serial interface (SPI)
  • Fast I2C 400 kHz SMBus and PMBus
  • USART (ISO 7816 interface and IrDA)
  • Up to 41 I/Os, all mappable on interrupt vectors
  • Fast on-chip programming and non-intrusive debugging with SWIM
  • Bootloader using USART
