S9S12GN32BMLCR Microcontroller MCU 25MHz 16-Bit HCS12 Microcontroller IC LQFP-32

S9S12GN32BMLCR Microcontroller MCU 25MHz 16-Bit HCS12 Microcontroller IC LQFP-32

Product Description Of S9S12GN32BMLCR

S9S12GN32BMLCR is a 16-bit automotive-grade/industrial-grade microcontroller from the S12G series, featuring the S12 core and designed for low-cost, high-reliability embedded control applications.

Specification Of S9S12GN32BMLCR

Features Of S9S12GN32BMLCR

S12 CPU core, 25 MHz bus and up to 240 KB on-chip flash with ECС
Up to 240 KB on-chip flash with ECC
Up to 4 KB EEPROM with ECС
Up to one multl-scalable controller area network (MSCAN) module (supporting CAN protocol 2.0A/B)
Up to three serlal communication Interface (SCI) modules supporting LIN communicatlons and up to three serlal perlpheral Interface (SPI) modules
Up to 12 KB on-chlp SRAM
Phase locked loop (IPLL) frequency multipller with
Internal filiter
Timer module (TIM) supporting up to elght channels that provide a range of 16-blt Input capture, output compare, counter and pulse accumulator functlons
Pulse width modulatlon (PWM) module with up to elght 8-blt channels
Up to 16-channel, 12-blt resolution successive approximation analog-to-digital converter (ADC)
Precislon fixed voltage reference for ADC converslons
On-chip voltage regulator (VREG) for regulatlon of Input supply and all Internal voltages
Analog comparator module 8-blt digital-to-analog converter (DAC)

Applications Of S9S12GN32BMLCR
Space-constrained applications
Body controllers
Door modules
HVAC
Seat controllers
Smart actuators
RKE receivers
Occupant detection
Lighting modules
Smart junction boxes
Fuel pumps
Oil pumps
