Product Description Of F280049PZSR

F280049PZSR is a C2000™ Piccolo™ series 32-bit real-time control MCU, designed specifically for industrial applications such as high-performance digital power supplies and motor control.

Specification Of F280049PZSR

Features Of F280049PZSR

• TMS320C28x 32-bit CPU
– 100MHz
– IEEE 754 single-precision Floating-Point Unit (FPU)
– Trigonometric Math Unit (TMU)
• 3×-cycle to 4×-cycle improvement for common trigonometric functions versus software libraries
• 13-cycle Park transform
– Viterbi/Complex Math Unit (VCU-I)
– Ten hardware breakpoints (with ERAD)
• Programmable Control Law Accelerator (CLA)
– 100MHz
– IEEE 754 single-precision floating-point instructions
– Executes code independently of main CPU
• On-chip memory
– 256KB (128KW) of flash (ECC-protected) across two independent banks
– 100KB (50KW) of RAM (ECC-protected or parity-protected)
– Dual-zone security supporting third-party development
– Unique Identification (UID) number
• Clock and system control
– Two internal zero-pin 10MHz oscillators
– On-chip crystal oscillator and external clock input
– Windowed watchdog timer module
– Missing clock detection circuitry
• 1.2V core, 3.3V I/O design
– Internal VREG or DC-DC for 1.2V generation allows for single-supply designs
– Brownout reset (BOR) circuit

Applications Of F280049PZSR

• Medium/short range radar
• Air conditioner outdoor unit
• Door operator drive control
• Automated sorting equipment
• CNC control
• Textile machine
• Welding machine
• AC charging (pile) station
• DC charging (pile) station
• EV charging station power module
• Wireless vehicle charging module
• Energy storage power conversion system (PCS)
• Central inverter
• Solar power optimizer
• String inverter
• DC/DC converter
• Inverter & motor control
• On-board (OBC) & wireless charger
• AC drive control module
• AC drive power stage module
• Linear motor power stage
• Servo drive control module
• AC-input BLDC motor drive
• DC-input BLDC motor drive
• Industrial AC-DC
• Three phase UPS
