STM32F103VDT6TR Microcontroller MCU High-Performance 32-Bit 72MHz ARM Cortex-M3 MCU

STM32F103VDT6TR Microcontroller MCU High-Performance 32-Bit 72MHz ARM Cortex-M3 MCU
STM32F103VDT6TR Microcontroller MCU High-Performance 32-Bit 72MHz ARM Cortex-M3 MCU

Large Image :  STM32F103VDT6TR Microcontroller MCU High-Performance 32-Bit 72MHz ARM Cortex-M3 MCU

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: STM32F103VDT6TR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 100-LQFP
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

STM32F103VDT6TR Microcontroller MCU High-Performance 32-Bit 72MHz ARM Cortex-M3 MCU

Description
Part Number: STM32F103VDT6TR Core Size: 32-Bit
Speed: 72MHz Number Of I/O: 80
Voltage - Supply (Vcc/Vdd): 2V ~ 3.6V Operating Temperature: -40°C ~ 85°C (TA)
Highlight:

STM32F103VDT6TR 32-bit microcontroller

,

ARM Cortex-M3 MCU 72MHz

,

High-performance microcontroller with warranty

STM32F103VDT6TR Microcontroller MCU
High-performance 32-bit ARM Cortex-M3 MCU operating at 72MHz frequency with extensive memory and peripheral capabilities.
Product Overview
The STM32F103VDT6TR incorporates the high-performance ARM® Cortex®-M3 32-bit RISC core operating at 72 MHz frequency, featuring high-speed embedded memories (Flash memory up to 512 Kbytes and SRAM up to 64 Kbytes), and an extensive range of enhanced I/Os and peripherals connected to two APB buses.
Key Specifications
Parameter Specification
Core Processor ARM® Cortex®-M3
Core Size 32-Bit
Speed 72MHz
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART, USB
Peripherals DMA, Motor Control PWM, PDR, POR, PVD, PWM, Temp Sensor, WDT
Number of I/O 80
Program Memory Size 384KB (384K x 8)
Program Memory Type FLASH
RAM Size 64K x 8
Voltage Supply 2V ~ 3.6V
Data Converters A/D 16x12b; D/A 2x12b
Oscillator Type Internal
Operating Temperature -40°C ~ 85°C (TA)
Technical Features
  • Core: ARM® 32-bit Cortex®-M3 CPU with 72 MHz maximum frequency
  • Performance: 1.25 DMIPS/MHz (Dhrystone 2.1) performance at 0 wait state memory access
  • Memory: 256 to 512 Kbytes of Flash memory, up to 64 Kbytes of SRAM
  • Memory Controller: Flexible static memory controller with 4 Chip Select supporting Compact Flash, SRAM, PSRAM, NOR and NAND memories
  • LCD Interface: LCD parallel interface with 8080/6800 modes
  • Power Management: 2.0 to 3.6 V application supply with POR, PDR, and programmable voltage detector (PVD)
  • Clock System: Multiple oscillator options including 4-to-16 MHz crystal, internal 8 MHz RC, and 32 kHz RTC oscillator
  • Low Power Modes: Sleep, Stop and Standby modes with VBAT supply for RTC
  • Analog Conversion: 3 × 12-bit, 1 μs A/D converters (up to 21 channels) with temperature sensor
  • Digital Conversion: 2 × 12-bit D/A converters
  • DMA: 12-channel DMA controller supporting multiple peripherals
  • Debug Capabilities: Serial wire debug (SWD) & JTAG interfaces with Embedded Trace Macrocell
  • I/O Ports: Up to 112 fast I/O ports, all mappable on 16 external interrupt vectors
  • Timers: Up to 11 timers including motor control PWM, watchdog, and basic timers
  • Communication Interfaces: Up to 13 interfaces including I2C, USART, SPI, CAN, USB, and SDIO
Related Electronic Components
Part Number Package
LCMXO3L-6900E-5MG256C 256-VFBGA
LCMXO3LF-4300E-5MG256C 256-VFBGA
LCMXO3L-2100C-5BG324C 324-CABGA
LCMXO3L-4300E-6MG256I 256-CSFBGA
LCMXO3LF-2100E-5MG324I 132-CSPBGA
LCMXO3LF-2100E-6MG256I 256-CSFBGA
LCMXO3LF-2100E-6MG324C 324-CSFBGA
LCMXO3L-4300C-5BG256C CSFBGA-256
LCMXO2-2000ZE-1MG132C 132-CSPBGA
LCMXO2-1200ZE-3TG100C 100-TQFP
