R5F104JGAFA 16-Bit Microcontroller MCU RL78/G14 Series 32MHz For Motor Control

R5F104JGAFA 16-Bit Microcontroller MCU RL78/G14 Series 32MHz For Motor Control
R5F104JGAFA 16-Bit Microcontroller MCU RL78/G14 Series 32MHz For Motor Control

Large Image :  R5F104JGAFA 16-Bit Microcontroller MCU RL78/G14 Series 32MHz For Motor Control

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: R5F104JGAFA
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: LQFP-52
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

R5F104JGAFA 16-Bit Microcontroller MCU RL78/G14 Series 32MHz For Motor Control

Description
Part Number: R5F104JGAFA Series: RL78/G14
Core Processor: RL78 Core Size: 16-Bit
Speed: 32MHz Number Of I/O: 38

R5F104JGAFA Microcontroller MCU RL78/G14 Series 16-Bit Microcontroller For Motor Control
R5F104JGAFA is a low power, high function, general purpose RL78/G14 Series 16-Bit Microcontroller designed for motor control, industrial, and metering applications. The built-in high-function timer supports three-phase motor control using three-phase complementary PWM output. It features an on-chip oscillator, data flash, A/D and D/A converters, comparator, and more.
Specifications
Product Category 16-bit Microcontrollers - MCU
Core RL78
Program Memory Size 512 kB
Data RAM Size 48 kB
Package / Case LQFP-52
Maximum Clock Frequency 32 MHz
ADC Resolution 8 bit, 10 bit
Number of I/Os 48 I/O
Supply Voltage - Min 1.6 V
Supply Voltage - Max 5.5 V
Mounting Style SMD/SMT
Data Bus Width 16 bit
Minimum Operating Temperature -40℃
Maximum Operating Temperature +105℃
Analog Supply Voltage 1.6 V to 5.5 V
DAC Resolution 8 bit
Data ROM Size 128 kB
Interface Type CSI, I2C, UART
Key Features
  • CPU: RL78 core, Max. 32MHz
  • Voltage: 1.6V to 5.5V
  • Package: 32 to 48-pin HWQFN, 48 to 100-pin LFQFP, 32 to 100-pin LQFP, 30-pin LSSOP, 36 to 64-pin WFLGA
  • Memory: SRAM Max. 48KB, Program Flash Max. 512KB
  • Timer: 16-bit Timer (ch) x 8, 8-bit Timer (ch) x 8, Watchdog Timer (ch) x 1, 12-bit Interval Timer x 1 ch
  • PWM: PWM Output x 13, 3-phase PWM Output Function
  • Analog function: 10-bit A/D Converter (ch) x 9, 8-bit D/A Converter (ch) x 2
  • On-chip Oscillator Freq. (MHz): High-Speed: 64, 48, 32, 24, 16, 12, 8, 6, 4, 3, 2, 1MHz; Low-speed: 15kHz
  • Others: RTC, Power-On Reset, Low Voltage Detection
Applications
  • Cordless Brushless Drill
  • Corded Hand Mixer
  • Pure Sine Wave Home Inverter with BMS
  • Cordless BLDC Hand Blender
  • Resistive Sensor Platform with IO‑Link
  • LoRaWAN Gas Meter
  • USB PD Adapter with Turbo Boost
  • Modbus ASCII/RTU Slave Board
  • Energy-Efficient High-End Electric Fan
