S32K312NHT0VPBST 32-Bit 120MHz ARM Cortex-M7 Microcontroller MCU for Automotive Applications

S32K312NHT0VPBST 32-Bit 120MHz ARM Cortex-M7 Microcontroller MCU for Automotive Applications
S32K312NHT0VPBST 32-Bit 120MHz ARM Cortex-M7 Microcontroller MCU for Automotive Applications

Large Image :  S32K312NHT0VPBST 32-Bit 120MHz ARM Cortex-M7 Microcontroller MCU for Automotive Applications

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: S32K312NHT0VPBST
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: QFP-172
Delivery Time: 3-5 work days
Payment Terms: TT
Supply Ability: 10000 Pieces per Day
Contact Now

S32K312NHT0VPBST 32-Bit 120MHz ARM Cortex-M7 Microcontroller MCU for Automotive Applications

Description
Part Number: S32K312NHT0VPBST Core Size: 32-Bit
Speed: Speed Number Of I/O: 143
Program Memory Size: 2MB (2M X 8) 2MB (2M X 8): -40°C ~ 105°C

S32K312NHT0VPBST Microcontroller MCU 32-Bit 120MHz ARM Cortex-M7 S32K3 Microcontroller

The S32K312NHT0VPBST extends the highly-scalable portfolio of Arm® Cortex®-M0+/M4F S32K1xx chips in the automotive industry with the Arm Cortex-M7 core at higher frequency, more memory, ASIL-B and D rating, and advanced security module. With a focus on automotive environment robustness, the S32K3xx product series devices are well suited to a wide range of applications in electrical harsh environments and are optimized for cost-sensitive applications offering new, space-saving package options.

Key Specifications
Package / Case QFP-172
Core ARM Cortex M7
Program Memory Size 2 MB
Data Bus Width 32 bit
Maximum Clock Frequency 160 MHz
Product Features
  • Scalable single platform with single, multiple, or lockstep Cortex-M7 cores (120MHz to 240MHz + FPU)
  • 512KB to 8MB Flash with ECC
  • FOTA - A/B firmware swap with zero downtime and roll-back support with automatic address translation
  • 12-bit 1Msps ADC, 16-bit eMIOS timer with logic control unit for motor control
  • Low-power run and standby modes, fast wake-up, clock, and power gating
  • MaxQFP and BGA packages
  • AEC-Q100 qualified Grade 1 of -40°C to +125°C
  • ISO 26262 up to ASIL B/D safety compliance
  • Fault collection and control unit with hardware and software watchdogs
  • HSE security engine with AES-128/192/256, RSA, ECC, secure boot, and key storage
  • Ethernet TSN/AVB (100Mbps/1Gbps), CAN FD, FlexIO, serial audio interface, QSPI
  • Production-grade software with S32 Design Studio IDE and comprehensive development tools
Target Applications
  • Advanced driver-assistance systems (ADAS)
  • Powertrain and chassis
  • Infotainment
  • Body and comfort systems
Related Product Variants
Part Number Package
AGFA019R24C3E3V BGA-2340
AGFA019R24C2E4X BGA-2340
AGFA019R24C2I1VB BGA-2340
AGFA019R24C3I3E BGA-2340
AGFA019R25A1I1V FBGA-2581
AGFA019R25A1E1V FBGA-2581
AGFA022R24C2E1V FBGA-2340
AGFA022R24C2E3E FBGA-2340
AGFA022R24C2E4X FBGA-2340
AGFA022R24C2I3V FBGA-2340
Frequently Asked Questions
Are your products original?
Yes, all products are original, new original import is our purpose.
Which Certificates do you have?
We are ISO 9001:2015 Certified Company and member of ERAI.
Can you support small quantity order or sample? Is the sample free?
Yes, we support sample order and small order. Sample cost is different according to your order or project.
How to ship my order? Is it safe?
We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
What about the lead time?
We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
