STM32L152RET6 Ultra-Low-Power 32-Bit 32MHz Arm Cortex-M3 MCU in LQFP-64 Package

STM32L152RET6 Ultra-Low-Power 32-Bit 32MHz Arm Cortex-M3 MCU in LQFP-64 Package
STM32L152RET6 Ultra-Low-Power 32-Bit 32MHz Arm Cortex-M3 MCU in LQFP-64 Package

Large Image :  STM32L152RET6 Ultra-Low-Power 32-Bit 32MHz Arm Cortex-M3 MCU in LQFP-64 Package

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: STM32L152RET6
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: LQFP-64
Delivery Time: 3-5 work days
Payment Terms: TT
Supply Ability: 10000 Pieces per Day
Contact Now

STM32L152RET6 Ultra-Low-Power 32-Bit 32MHz Arm Cortex-M3 MCU in LQFP-64 Package

Description
Part Number: STM32L152RET6 Core Size: 32-Bit
Speed: 32MHz Number Of I/O: 51
Operating Temperature: -40°C ~ 85°C (TA) Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V

STM32L152RET6 Ultra-Low-Power 32-Bit 32MHz Arm Cortex-M3 MCU In LQFP-64 Package

The ultra-low-power STM32L152RET6 devices incorporate the connectivity power of the universal serial bus (USB) with the high-performance Arm® Cortex®-M3 32-bit RISC core operating at a frequency of 32 MHz (33.3 DMIPS), a memory protection unit (MPU), high-speed embedded memories (Flash memory up to 512 Kbytes and RAM up to 80 Kbytes), and an extensive range of enhanced I/Os and peripherals connected to two APB buses.

Specifications
Parameter Value
Core ARM Cortex M3
Program Memory Size 512 kB
Data Bus Width 32 bit
ADC Resolution 12 bit
Maximum Clock Frequency 32 MHz
Number of I/Os 51 I/O
Data RAM Size 80 kB
Supply Voltage - Min 1.65 V
Supply Voltage - Max 3.6 V
Minimum Operating Temperature -40 °C
Maximum Operating Temperature +85 °C
Analogue Supply Voltage 1.65 V to 3.6 V
DAC Resolution 12 bit
Data RAM Type SRAM
Data ROM Size 16 kB
Data ROM Type EEPROM
I/O Voltage 1.65 V to 3.6 V
Interface Type I2C, I2S, SPI, USART, USB
Moisture Sensitive Yes
Number of ADC Channels 21 Channel
Unit Weight 342.700 mg
Key Features
  • Includes ST state-of-the-art patented technology
  • Ultra-low-power platform
  • 1.65 V to 3.6 V power supply
  • -40 °C to 105 °C temperature range
  • 290 nA Standby mode (3 wakeup pins)
  • 1.11 µA Standby mode + RTC
  • 560 nA Stop mode (16 wakeup lines)
  • 1.4 µA Stop mode + RTC
  • 11 µA Low-power run mode down to 4.6 µA in Low-power sleep mode
  • 195 µA/MHz Run mode
  • 10 nA ultra-low I/O leakage
  • 8 µs wakeup time
  • Core: Arm® Cortex®-M3 32-bit CPU
  • From 32 kHz up to 32 MHz max
  • 1.25 DMIPS/MHz (Dhrystone 2.1)
  • Memory protection unit
  • Up to 34 capacitive sensing channels
  • CRC calculation unit, 96-bit unique ID
  • Reset and supply management
  • Low-power, ultrasafe BOR (brownout reset) with 5 selectable thresholds
  • Ultra-low-power POR/PDR
  • Programmable voltage detector (PVD)
  • Clock sources: 1 to 24 MHz crystal oscillator, 32 kHz oscillator for RTC with calibration, internal 16 MHz oscillator factory trimmed RC(+/-1%) with PLL option, internal low-power 37 kHz oscillator, internal multispeed low-power 65 kHz to 4.2 MHz oscillator, PLL for CPU clock and USB (48 MHz)
  • Pre-programmed bootloader (USB and USART supported)
  • Up to 116 fast I/Os (102 I/Os 5V tolerant), all mappable on 16 external interrupt vectors
  • Memories: 512 Kbytes of Flash memory with ECC, 80 Kbytes of RAM, 16 Kbytes of true EEPROM with ECC, 128-byte backup register
  • LCD driver up to 8x40 segments, contrast adjustment, blinking mode, step-up converter
  • Rich analog peripherals (down to 1.8 V): 2x operational amplifiers, 12-bit ADC 1 Msps up to 40 channels, 12-bit DAC 2 ch with output buffers, 2x ultra-low-power comparators (window mode and wake up capability)
  • DMA controller 12x channels
  • 11x peripheral communication interfaces: 1x USB 2.0 (internal 48 MHz PLL), 5x USARTs, up to 8x SPIs (2x I2S, 3x 16 Mbit/s), 2x I2Cs (SMBus/PMBus)
  • 11x timers: 1x 32-bit, 6x 16-bit with up to 4 IC/OC/PWM channels, 2x 16-bit basic timers, 2x watchdog timers (independent and window)
  • Development support: serial wire debug, JTAG and trace
