S9S12XS128J1MAA 40MHz 16-Bit HCS12X Microcontroller MCU with 128KB Flash for Automotive Applications

S9S12XS128J1MAA 40MHz 16-Bit HCS12X Microcontroller MCU with 128KB Flash for Automotive Applications
S9S12XS128J1MAA 40MHz 16-Bit HCS12X Microcontroller MCU with 128KB Flash for Automotive Applications

Large Image :  S9S12XS128J1MAA 40MHz 16-Bit HCS12X Microcontroller MCU with 128KB Flash for Automotive Applications

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: S9S12XS128J1MAA
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: QFP-80​
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

S9S12XS128J1MAA 40MHz 16-Bit HCS12X Microcontroller MCU with 128KB Flash for Automotive Applications

Description
Part Number: S9S12XS128J1MAA Core Processor: HCS12X
Core Size: 16-Bit Speed: 40MHz
Number Of I/O: 59 Program Memory Size: 128KB (128K X 8)
Highlight:

40MHz HCS12X Microcontroller

,

128KB Flash Microcontroller MCU

,

Automotive-Grade 16-Bit Microcontroller

S9S12XS128 Microcontroller MCU 40MHz 16-Bit HCS12X Microcontroller IC QFP-80
Product Overview Of S9S12XS128

S9S12XS128 is a 16-bit automotive-grade microcontroller (MCU) from the S12XS series, based on the enhanced S12X CPU, featuring 128 KB of Flash memory and housed in an 80-pin QFP package. It is commonly used in embedded applications such as automotive body control, industrial control and CAN nodes.

Specifications Of S9S12XS128
Product Category 16-bit Microcontrollers - MCU
Program Memory Size 128 kB
Data RAM Size 8 kB
Package / Case PQFP-80
Maximum Clock Frequency 40 MHz
ADC Resolution 12 bit
Number of I/Os 91 I/O
Supply Voltage - Min 1.72 V
Supply Voltage - Max 1.98 V
Mounting Style SMD/SMT
Data Bus Width 16 bit
Minimum Operating Temperature -40 ℃
Maximum Operating Temperature +125 ℃
Analog Supply Voltage 3.13 V to 5.5 V
I/O Voltage 3.13 V to 5.5 V
Interface Type CAN, SCI, SPI
Number of ADC Channels 16 Channel
Number of Timers/Counters 12 Timer
Operating Supply Voltage 1.72 V 1.98 V
Key Features Of S9S12XS128
  • Enhanced S12X architecture, backwards compatible with the S12 instruction set
  • 128KB on-chip Flash, supporting in-circuit programming and erasure
  • 8KB RAM + 8KB D-Flash, suitable for data storage and EEPROM emulation
  • Integrated CAN bus, suitable for automotive and industrial network nodes
  • Supports BDM debugging and bootloader development
  • Multiple low-power modes, suitable for automotive electronics and embedded control
  • Automotive-grade reliability with strong immunity to interference
Applications Of S9S12XS128
  • Automotive Body Control Module (BCM)
  • Automotive HVAC, lighting, door, window and seat controls
  • Automotive CAN nodes and sensor nodes
  • Industrial control, motor control and embedded control systems
