TMS320F28027FPTTR Microcontroller MCU C2000™ 32-bit 60MHz MCU With 64 KB Flash

TMS320F28027 microcontrollers provide the power of the C28x core coupled with highly integrated control peripherals in low pin-count devices. This family is code-compatible with previous C28x-based code and offers a high level of analog integration.

• High-efficiency 32-bit CPU (TMS320C28x)
• 60 MHz (16.67-ns cycle time), 50 MHz (20-ns cycle time), 40 MHz (25-ns cycle time)
• 16 × 16 and 32 × 32 MAC operations, 16 × 16 dual MAC
• Harvard bus architecture with atomic operations
• Fast interrupt response and processing
• Unified memory programming model
• Code-efficient (in C/C++ and Assembly), Little endian
• Low cost system design: Single 3.3-V supply, no power sequencing requirement
• Integrated power-on and brown-out resets
• Small packaging, as low as 38-pin available
• Low power consumption with no analog support pins
• Clocking: Two internal zero-pin oscillators, on-chip crystal oscillator and external clock input
• Watchdog timer module with missing clock detection circuitry
• Up to 22 individually programmable, multiplexed GPIO pins with input filtering
• Peripheral Interrupt Expansion (PIE) block supporting all peripheral interrupts
• Three 32-bit CPU timers plus independent 16-bit timer in each Enhanced PWM
• On-chip memory: Flash, SARAM, OTP, Boot ROM available
• Code-security module with 128-bit security key and lock
• Serial port peripherals: SCI UART, SPI, and I2C modules
• Enhanced control peripherals: ePWM, High-Resolution PWM, Enhanced Capture module
• Analog-to-Digital Converter (ADC) with on-chip temperature sensor and comparator
• Advanced emulation features with analysis and breakpoint functions
• Package options: 38-pin DA TSSOP, 48-pin PT LQFP
• Temperature options: -40°C to 105°C, -40°C to 125°C, automotive qualified options available

• Air conditioner outdoor unit
• Inverter & motor control
• Textile machine
• Micro inverter
• AC drive power stage module
• AC-input BLDC motor drive
• DC-input BLDC motor drive
• Industrial AC-DC
• Three phase UPS
• Merchant DC/DC
• Merchant network & server PSU
• Merchant telecom rectifiers
