STM8S903K3T6CTR Microcontroller MCU STM8S Mainstream 8-Bit 16MHz Microcontroller

STM8S903K3T6CTR Microcontroller MCU STM8S Mainstream 8-Bit 16MHz Microcontroller
STM8S903K3T6CTR Microcontroller MCU STM8S Mainstream 8-Bit 16MHz Microcontroller

Large Image :  STM8S903K3T6CTR Microcontroller MCU STM8S Mainstream 8-Bit 16MHz Microcontroller

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: STM8S903K3T6CTR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: LQFP-32
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

STM8S903K3T6CTR Microcontroller MCU STM8S Mainstream 8-Bit 16MHz Microcontroller

Description
Part Number: STM8S903K3T6CTR Core Size: 8-Bit
Speed: 16MHz Connectivity: I2C, IrDA, LINbus, SPI, UART/USART
Number Of I/O: 28 Voltage - Supply (Vcc/Vdd): 2.95V ~ 5.5V
Highlight:

8-Bit Microcontroller

,

16MHz MCU

,

28 I/O Microcontroller

STM8S903K3T6CTR Microcontroller MCU STM8S Mainstream 8-Bit 16MHz Microcontroller
Product Overview Of STM8S903

The STM8S903K3T6CTR is a mainstream 8-bit microcontroller from the STM8S access line, offering 8 Kbyte of Flash program memory plus integrated true data EEPROM. Referred to as low-density devices in the STM8S microcontroller family reference manual (RM0016), these MCUs deliver performance, robustness, and reduced system cost.

Specifications Of STM8S903
Core STM8
Program Memory Size 8 kB
Data RAM Size 1 kB
Package / Case LQFP-32
Maximum Clock Frequency 16 MHz
ADC Resolution 10 bit
Number of I/Os 28 I/O
Supply Voltage - Min 2.95 V
Supply Voltage - Max 5.5 V
Data Bus Width 8 bit
Minimum Operating Temperature -40 °C
Maximum Operating Temperature +85 °C
Data ROM Size 640 B
Data ROM Type EEPROM
Interface Type I2C, SPI, UART
Moisture Sensitive Yes
Number of ADC Channels 7 Channel
Key Features Of STM8S903
Core
  • 16 MHz advanced STM8 core with Harvard architecture and 3-stage pipeline
  • Extended instruction set
Memories
  • Program memory: 8 Kbyte Flash; data retention 20 years at 55 °C after 10 kcycle
  • Data memory: 640 byte true data EEPROM; endurance 300 kcycle
  • RAM: 1 Kbyte
Clock, Reset and Supply Management
  • 2.95 to 5.5 V operating voltage
  • Flexible clock control with 4 master clock sources
  • Low power crystal resonator oscillator
  • External clock input
  • Internal, user-trimmable 16 MHz RC
  • Internal low-power 128 kHz RC
  • Clock security system with clock monitor
  • Power management: low-power modes (wait, active-halt, halt)
  • Switch-off peripheral clocks individually
  • Permanently active, low-consumption power-on and power-down reset
Interrupt Management
  • Nested interrupt controller with 32 interrupts
  • Up to 28 external interrupts on 7 vectors
Timers
  • Advanced control timer: 16-bit, 4 CAPCOM channels, 3 complementary outputs, dead-time insertion and flexible synchronization
  • 16-bit general purpose timer with 3 CAPCOM channels (IC, OC or PWM)
  • 8-bit basic timer with 8-bit prescaler
  • Auto wake-up timer
  • Window watchdog and independent watchdog timers
Communication Interfaces
  • UART with clock output for synchronous operation, SmartCard, IrDA, LIN master mode
  • SPI interface up to 8 Mbit/s
  • I2C interface up to 400 kbit/s
Analog to Digital Converter (ADC)
  • 10-bit, ±1 LSB ADC with up to 7 multiplexed channels + 1 internal channel, scan mode and analog watchdog
  • Internal reference voltage measurement
I/Os and Unique ID
  • Up to 28 I/Os on a 32-pin package including 21 high sink outputs
  • Highly robust I/O design, immune against current injection
  • 96-bit unique key for each device
