The C8051F330 is an 8-bit, 8051-compatible mixed-signal microcontroller (MCU) housed in a compact 20-pin QFN package. It integrates 8 kB of Flash memory, a 10-bit ADC, a comparator, an internal oscillator, and a variety of serial interfaces, making it well suited for compact, low-pin-count embedded applications that require analog acquisition and control.

• Pipelined instruction architecture; executes 70% of instructions in 1 or 2 system clocks
• Up to 25 MIPS throughput with a 25 MHz clock
• Expanded interrupt handler

• 768 bytes internal data RAM (256 + 512)
• 8 kB ('F330/1), 4 kB ('F332/3), or 2 kB ('F334/5) Flash; in-system programmable in 512-byte sectors — 512 bytes are reserved in the 8 kB devices

• 17 Port I/O; all 5 V tolerant with high sink current
• Hardware-enhanced UART, SMBus™, and enhanced SPI™ serial ports
• Four general-purpose 16-bit counter/timers
• 16-bit programmable counter array (PCA) with three capture/compare modules
• Real-time clock mode using PCA or timer and external clock source

• Two internal oscillators:
  • 24.5 MHz with ±2% accuracy, supporting crystal-less UART operation
  • 80/40/20/10 kHz low-frequency, low-power
• External oscillator: crystal, RC, C, or clock (1- or 2-pin modes)
• Can switch between clock sources on the fly; useful in power-saving modes

• 10-bit ADC ('F330/2/4 only)
  • Up to 200 ksps
  • Up to 16 external single-ended or differential inputs
  • VREF from internal VREF, external pin, or VDD
  • Internal or external start-of-conversion source
  • Built-in temperature sensor
• 10-bit current output DAC ('F330 only)
• Comparator
  • Programmable hysteresis and response time
  • Configurable as interrupt or reset source
  • Low current (0.4 µA)

• On-chip debug circuitry facilitates full-speed, non-intrusive in-system debug (no emulator required)
• Provides breakpoints, single stepping, and inspect/modify memory and registers
• Superior performance to emulation systems using ICE-chips, target pods, and sockets
• Low-cost, complete development kit

• Supply voltage: 2.7 to 3.6 V
• Typical operating current: 6.4 mA at 25 MHz; 9 µA at 32 kHz
• Typical stop mode current: 0.1 µA
• Temperature range: -40 to +85 °C
• 20-pin QFN package

• Small-scale sensor acquisition and signal conditioning
• Portable electronic devices
• Industrial control and monitoring modules
• Consumer electronics
• Auxiliary power management control
• Auxiliary motor control circuits
• Data acquisition modules
• Low-pin-count embedded control boards
